Vertical Edge Deletion Machine Insulating Glass Hollow Glasing Double Glazing

Name: Vertical Edge Deletion Machine Insulating Glass Hollow Glasing Double Glazing
Brand: Jinan Lijiang Glass Machinery
Price: 1 USD

Brand Name : Jinan Lijiang Glass Machinery

Model Number : LJCM2545 Smart Vertical Edge Deleting Machine

Certification : CE & ISO9000

Place of Origin : Jinan City, Shandong Province, China

MOQ : 1 set

Price : Negotiated Price

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 20 sets per month

Delivery Time : 5-8 working days

Packaging Details : Wooden Cases Package

Name : Vertical Glass edge deleting machine

Dimension : 9700*2500*3400mm

Edge deleting width : 10-150mm

Glass thickness : 3-15mm

Max. glass process : 2500*4500mm

Min. glass process : 400*280mm

Edge deleting speed : 2-29m/min

Air pressure : ≥0.8MPa

Contact Now

Automatic Vertical Insulating Glass Hollow Glasing Double Glazing Edge Deleting Machine

Product Description

Vertical Edge Deletion Machine Insulating Glass Hollow Glasing Double Glazing

Automatic Vertical Edge Deleting Machine LJCM2545

LJCM2545 Vertical side deleting computing device is specialised for LOW-E glass movie remover. It adopts a vertical shape and manufacturing line for handy connection. Glass aspect deleting computing devices is easy and efficient. It adopts an imported servo manage machine for transmission, correct positioning, and steady operation. Low-e glass movie remover is specialized for LOW-E glass movie remover. It adopts a vertical shape and manufacturing line for convenient connection.

Technical parameter

Item,	Spec.
Max. glass processing size	2500*4500mm
Min. glass processing size	400*280mm
Glass thickness	3-15mm
Diameter of grinding wheel	200mm
Conveyor height	500mm
Edge deleting width	10-50mm
Transmission speed	1. 29m/min
Edge deleting speed	2-29m/min
Abrasive wheel width	10/12/15mm
Glass thickness	3 - 15mm
Grinding wheel speed	0~3000r/min
Total air consumption	100L/ min
Air pressure	≥0.8MPa
Total power	3P 380V 50Hz 3.35KW
Dimension	Dimensions :9700×2500×3400mm
Total weight	3700KG

NAME	ORIGIN	BRAND
Servo motor	Taiwan	TAIDA
PLC	Taiwan	TAIDA
Pneumatic component	Taiwan	AAIRTAC
Low pressure electricity	Germany	SIEMENS
Circuit breaker	Germany	SIEMENS
Sensor switch	Korea	AUTONICS
Approach switch	Korea	AUTONICS
Limit switch	Taiwan	TEND
Connector	Germany	SIEMENS
Frequency converter	France	SCHNEIDER
Main Button	France	SCHNEIDER
Intermediate relay	Japan	OMRON

Advantages & Features

Benefits & Advantages

1) The automated computing device is outfitted with a full servo deliver device and Germany Simons manage system.
 2) It is successful of getting rid of the scalene movie with one operation. The deleting width for the overlapped place is additionally adjustable
 3) Manual operations are reachable for every function, beneficial in debugging and maintenance.
 4) It is geared up with a dirt suction system to mitigate dirt pollution.
 5) The enter section and output section can be run asynchronously, enhancing productivity.
 6) The stripping pace is adjustable (according to unique movie kinds and predicted stripping effect).
 7) Six servo motor manage structures and an adjustable linear dimension are furnished to warranty a greater accuracy for arc/shapes.
 8) The vertical low-e part deletion laptop can manage particularly fashioned glass panels, such as the glass panels with holes for point-supported glass curtain wall system.
 9) The stripping width tolerance is smaller than 1mm, the stripping effectivity is >90% (for reference).

The Smooth Glue Surface

After making use of glue, It will make sure that the corners of the glass are full, besides bubbles and different impurities, and the glue floor is so smooth.

The High-precision Servo Control System

It adopts a Japanese Yaskawa servo manipulate device with a clear wiring format to make certain the steady average overall performance of the equipment.

The Glass Coating

Automatically measure glass size, glue depth, and glue velocity thru the linear adjustment to make sure the steadiness of insulating glass coating quality.

Glue Pump A and Glue Pump B

Equipped with a single A factor and a single B component, combined and glued. When making use of glue, glue pump A and glue pump B are routinely combined to understand computerized proportioning.
